Home >> Products >> PUR Cable >> UL10774 Electrical equipment cableDetailed description
UL10774 Electrical equipment cable
Prv：UL10775 FR-PE CABLENext：UL10533 PUR Cable

Electrical equipment cable,PUR Cable,electric wire,electrical wire,China cable,Copper cable

Product Description:

1)  Tinned, annealed,stranded or solid copper conductor.

2)  PUR jacketed.Jacket thickness:30mils

3)  Rated temperature:80°C.Rated voltage: 30 volts.

4) Conductor:36 AWG min. solid or stranded round, tinned or bare copper

5) Passes UL VW-1 & CSA FT1 horizontal flame test.

6)  Executive Standard:UL758,UL1581,CSA22.2.

Applications:

Internal wiring.

UL Style& CUL Type Conductor Insulation
Thickness		 Jacket
Thickness		 Overall
Diameter		 Standard Put-up Conductor
Resistance at 20℃
AWG No/mm mm mm mm Ft/coil M/Coil Ω/KM
UL10774
CUL  AWM FT1 I A/B
(Stranded)
 26 7/0.16 0.23 0.76 2.50 1000 305 150.00
24 11/0.16 0.23 0.76 2.60 1000 305 94.20
22 17/0.16 0.23 0.76 2.90 1000 305 59.40
20 21/0.178 0.23 0.76 3.10 1000 305 36.70
18 34/0.178 0.23 0.76 3.30 1000 305 23.20
16 26/0.25 0.23 0.76 3.60 1000 305 14.60
UL10774
CUL  AWM FT1 I A/B
（Stranded)		 28 7/0.127 0.23 0.76 2.40 1000 305 248.00
26 7/0.16 0.23 0.76 2.50 1000 305 150.00
24 7/0.20 0.23 0.76 2.60 1000 305 88.70
22 7/0.254 0.23 0.76 2.90 1000 305 54.70
20 7/0.32 0.23 0.76 3.10 1000 305 37.10
UL10774
CUL  AWM FT1 I A/B
（Stranded)		 26 1/0.404 0.23 0.76 2.50 1000 305 143.00
24 1/0.511 0.23 0.76 2.60 1000 305 89.30
22 1/0.634 0.23 0.76 2.90 1000 305 56.40
20 1/0.813 0.23 0.76 3.10 1000 305 35.20
18 1/1.024 0.23 0.76 3.30 1000 305 22.20
