UL20863 Heating cable
Product Description:
1.Tinned,annealed,stranded or solid copper conductor.
2.TPE insulation.TPE jacketed.
3.Rated temperature: 105°C.Rated voltage: 600volts.
4.Tinned or bare copper wire spiral or braid shield
5.Passes UL VW-1&CUL FT1 vertical flame test
Applications:
Pipe Heating Cable where the acceptability of the combination is to be determined by Underwriters Laboratories Inc.
UL Style& CUL Type
Cores
Conductor
Insulation
ThicknessNom.Dia
Shield Coverage
Jacket Thickness
Overall
DimeterConductor
Resistance at 20℃
AWG
No/mm
mm
mm
%
mm
mm
Ω/KM
UL20863
CUL
（Stranded)2C
18
34/0.178
0.76
2.80
>=65
1.016
8.20
23.20
16
26/0.25
0.76
3.10
>=65
1.016
8.80
14.60
14
41/0.25
0.76
3.50
>=65
1.016
9.60
8.96
12
65/0.25
0.76
4.00
>=65
1.016
10.6
5.64
UL20863
CUL
（Stranded)3C
18
34/0.178
0.76
2.80
>=65
1.016
8.60
23.20
16
26/0.25
0.76
3.10
>=65
1.016
9.20
14.60
14
41/0.25
0.76
3.50
>=65
1.016
10.20
8.96
12
65/0.25
0.76
4.00
>=65
1.016
11.4
5.64
UL20863
CUL
（Stranded)4C
18
34/0.178
0.76
2.80
>=65
1.016
9.40
23.20
16
26/0.25
0.76
3.10
>=65
1.016
10.20
14.60
14
41/0.25
0.76
3.50
>=65
1.016
11.20
8.96
12
65/0.25
0.76
4.00
>=65
1.016
12.4
5.64
