UL10369 XL-PE Insulated Wire
Prv：UL10428 XL-PE Insulated WireNext：UL10368 XL-PE Insulated Wire

Product Description:
1）Tinned,annealed,stranded or solid copper conductor.
2) XL-PE insulation.
4）Rated temperature:105℃.Rated voltage:600volts.
5）Uniform thickness of wire to ensure easy stripping and cutting.
6）Passes UL VW-1 & CSA FT1 vertical flame test or horizontal flame text.
7）Executive Standard:UL758,UL1581,CSA22.2.
Applications:
1）For general purpose internal wiring of electronic and electrical equipment.

UL Style & CSA Type Conductor Insulation
Thickness		 Overall
Diameter		 Standard Put-up Conductor
Resistance at 20℃
AWG No/mm mm mm Ft/coil M/Coil Ω/KM
UL10369
（Stranded)		 26 7/0.160 0.51 1.60 2000 610 150.00
24 11/0.160 0.51 1.70 2000 610 94.20
22 17/0.160 0.51 1.80 2000 610 59.40
20 21/0.178 0.51 2.10 2000 610 36.70
18 34/0.178 0.51 2.40 2000 610 23.20
16 26/0.250 0.51 2.60 1000 305 14.60
14 41/0.250 0.51 3.00 1000 305 8.96
12 65/0.250 0.51 3.50 1000 305 5.64
10 105/0.250 0.51 4.00 1000 305 3.55
UL10369  (Top-coated) 26 7/0.160 0.51 1.60 2000 610 150.00
24 7/0.200 0.51 1.70 2000 610 94.20
22 7/0.250 0.51 1.80 2000 610 59.40
UL10369 (Solid) 26 1/0.404 0.51 1.50 2000 610 143.00
24 1/0.505 0.51 1.60 2000 610 89.30
22 1/0.634 0.51 1.70 2000 610 56.40
20 1/0.813 0.51 1.90 2000 610 35.20
18 1/0.102 0.51 2.10 2000 610 22.20
