silicone rubber wire UL3068
Product Description
Conductor：30AWG---16AWG
Tinned,annealed,stranded or solid copper conductor.
Silicone Rubber insulation,Braid:Fiberglass+Silicone
Rated temperature:150℃.Rated voltage:300volts
Uniform thickness of wire to ensure easy stripping and cutting.
Passes UL VW-1&CUL FT1 vertical flame test
Top coated conductor is available
Applications:
Apply to Household appliance,lumination&Lighting Metallurgy&Headlamp,electric machines、tempurature
senso,Military series,Metallurgy Chemical series,Motor cars&Ships,Electrical installation
| UL Style& Cul Type | Conductor | Insulation
Thickness
|
Overall
Diameter
|
Standard Put-up | Conductor
Resistance at 20℃
|
||
| AWG | No/mm | mm | mm | Ft/Reel | M/Reel | Ω/KM | |
UL3068
CUL AWM I A
（Stranded)
|
30 | 7/0.10 | 0.38 | 1.35 | 2000 | 610 | 381 |
| 28 | 7/0.127 | 0.38 | 1.42 | 2000 | 610 | 239 | |
| 26 | 7/0.16 | 0.38 | 1.55 | 2000 | 610 | 150 | |
| 24 | 7/0.20 | 0.38 | 1.70 | 2000 | 610 | 94.2 | |
| 11/0.16 | 0.38 | 1.70 | 2000 | 610 | |||
| 22 | 7/0.25 | 0.38 | 1.85 | 2000 | 610 | 59.4 | |
| 17/0.16 | 0.38 | 1.85 | 2000 | 610 | |||
| 20 | 7/0.31 | 0.38 | 2.05 | 2000 | 610 | 36.70 | |
| 21/0.178 | 0.38 | 2.05 | 2000 | 610 | |||
| 18 | 7/0.39 | 0.38 | 2.28 | 2000 | 610 | 23.20 | |
| 34/0.178 | 0.38 | 2.28 | 2000 | 610 | |||
| 16 | 7/0.50 | 0.38 | 2.63 | 2000 | 610 | 14.60 | |
| 26/0.25 | 0.38 | 2.63 | 2000 | 610 | |||
UL3068
CUL AWM I A
（Stranded)
|
30 | 1/0.25 | 0.38 | 1.35 | 2000 | 610 | 354 |
| 28 | 1/0.32 | 0.38 | 1.42 | 2000 | 610 | 223 | |
| 26 | 1/0.40 | 0.38 | 1.55 | 2000 | 610 | 140 | |
| 24 | 1/0.50 | 0.38 | 1.62 | 2000 | 610 | 87.5 | |
| 22 | 1/0.64 | 0.38 | 1.75 | 2000 | 610 | 55.0 | |
| 20 | 1/0.81 | 0.38 | 1.92 | 2000 | 610 | 34.6 | |
| 18 | 1/1.02 | 0.38 | 2.12 | 2000 | 610 | 21.8 | |
| 16 | 1/1.29 | 0.38 | 2.43 | 2000 | 610 | 13.7 | |
